Harxon is a leading manufacturer of high-precision GNSS antennas for UAVs (unmanned aerial vehicles), UGVs (unmanned ground vehicles) and robotic systems. Our products are ideal for a wide range of positioning requirements for drones and autonomous vehicles, in fields such as civil aviation, precision agriculture, and mapping and surveying.

Smart Antennas

Accurate RTK positioning for unmanned vehicles

Harxon Smart AntennasOur Smart GNSS Antennas for base stations and rovers provide advanced multi-constellation positioning for precision agriculture and other UGV applications.

All units feature Bluetooth functionality, and all except the TS112SE provide 3G, 4G and external/internal radio modem options for flexible communications capabilities.

Rover Series antennas offer RTK positioning for enhanced accuracy, and provide simultaneous satellite tracking allowing autonomous farm vehicles and UGVs to receive signals even under challenging and obstructing conditions. Our patented T-DIFF technology ensures exceptional pass-to-pass accuracy down to centimetre-level, with sophisticated algorithms for tilt and vibration compensation.

TS100 Series Rover gnss smart antenna
TS100 Rover
TS300 Rover gnss smart antenna
TS300 Rover
TS100 Series Base gnss smart antenna
TS100 Base

The Base Series antenna, also providing RTK positioning capabilities, features a multi-point feeding design for greater phase center stability as well as advanced multi-path resistance technology. The unit delivers enhanced measurement accuracy, precision and stability even in difficult environments.

Harxon Smart Antenna TS112
TS112
Harxon Smart Antenna TS112 SE
TS112 SE
Harxon Smart Antenna TS112 PRO
TS112 PRO

Additionally, the TS112 family of smart rover antennas features either Harxon SLIDE or Hexagon | NovAtel GLIDE technology for enhanced accuracy and smooth linear positioning, as well as a sophisticated terrain compensation algorithm that corrects deviations caused by vehicle roll and pitch on uneven ground.

Specifications:

Harxon Smart Antenna TS112TS112 Harxon Smart Antenna TS112 SETS112 SE Harxon Smart Antenna TS112 PROTS112 PRO
Dimensions
(diameter x height)
210 x 155 x 80 mm
Weight < 600g
Power Consumption 2.5W typical, <10W max
Satellite Signals GPS L1/L2
GLONASS L1/L2
BDS B1/B2
GALILEO E1/E5b
SBAS L1
GPS L1/L2
GLONASS L1/L2
BDS B1/B2
GALILEO E1/E5b
SBAS L1
L-Band
GPS L1/L2/L5
GLONASS L1/L2
BDS B1/B2
GALILEO E1/E5a2
/E5b/AltBOC
NavIC(IRNSS) L5
SBAS WAAS/EGNOS
/MSAS/GAGAN/QZSS
L-Band
Horizontal Position Accuracy Single point 1.5m CEP
DGPS 0.4m CEP
SBAS 0.6m CEP
RTK 1cm + 1ppm CEP
Single point 1.5m CEP
DGPS 0.4m CEP
SBAS 0.6m CEP
SAPA(Basic) Below 1m to 10cm CEP
SAPA(Premium) Below 10cm CEP
Single Point L1 1.5m
Single Point L1/L2 1.2m
SBAS 60 cm
DGPS 40 cm
TerraStar-L 40 cm
TerraStar-C 4 cm
RTK 1 cm + 1 ppm
Velocity Accuracy 0.05m/s RMS
Max Position Data Rate 10 Hz max 20 Hz max
TS100 Series Rover gnss smart antennaTS100 Rover TS300 Rover gnss smart antennaTS300 Rover TS100 Series Base gnss smart antennaTS100 Base
Dimensions
(diameter x height)
160 x 80 mm
Weight <850g <850g <950g
Power Consumption <4.5W <3.5W <8.5W
Satellite Signals GPS L1/L2/L5
GLONASS L1/L2
BDS B1/B2/B3
GALILEO E1/E5a/E5b
GPS L1
GLONASS L1
BDS B1
GALILEO E1
SBAS
GPS L1/L2/L5
GLONASS L1/L2
BDS L1/L2/L3
GALILEO E1/E5a/E5b
Horizontal Position Accuracy Single point 1.5m
DGPS 0.4m
RTK 1cm + 1ppm
Single point 1.5m
DGPS 0.4m
RTK 1cm + 1ppm
Single point 1.5m
Velocity Accuracy 0.03 m/s RMS N/A
Max Position Data Rate 10 Hz

More Information: Smart Antennas

Webinar: Harxon’s New Generation Smart Antenna Virtual Launch

Ruggedized Antennas

IP67-rated antennas for unmanned vehicles

Our ruggedized antennas, featuring IP6x rated housing for reliable operation in harsh environments, are designed to be easily integrated into unmanned systems and autonomous vehicles. Providing full support for all frequencies across all constellations, as well as L-band corrections, the antennas incorporate advanced filtering and anti-interference capabilities as well as robust signal tracking.

harxon ruggedized antennas

The high-gain antennas deliver exceptional low elevation signal tracking and wide-angle circular polarization performance even under challenging conditions, and take advantage of advanced multipoint feeding technology for a highly stable phase centre.

Specifications:

HX-CVX600A Ruggedized GNSS IP67 AntennaHX-CVX600A HX-CVX603A Ruggedized IP67 AntennaHX-CVX603A
Dimensions
(diameter x height)
150 x 53 mm 90.6 x 26 mm
Weight <600g <250g
Satellite Signals GPS L1/L2/L5
GLONASS L1/L2/L3
GALILEO E1/E5a/E5b/E6
BDS B1/B2/B3
QZSS L1/L2/L5/L6
IRNSS L5
SBAS L1/L5
L-Band
Peak Gain 5.5 dBi 4.0 dBi
LNA Gain 40 ± 2 dB
LNA Noise <2 dB
Ingress Protection IP67, IP69K IP67

More Information: Ruggedized Antennas

Webinar: Harxon Releases Two New GNSS Antennas for Autonomous Applications

GNSS Survey Antennas

High-accuracy, survey grade antennas

Our GNSS antennas for surveying applications provide high precision and reliable data even under the most challenging of conditions. With an advanced multi-point feeding design for greater phase center stability, they are highly suitable for high-accuracy surveying requirements in environments such as dense tree lines or construction sites.

The compact and lightweight antennas are ideal for incorporation into a wide range of unmanned systems, autonomous precision agriculture vehicles and robotic platforms. OEM board and rugged dust- and water-resistant IP67-rated enclosure options are available.

Specifications:

GPS1000 Survey Grade AntennaGPS1000 Mini Survey Antenna GPS600GPS600 HX-CSX100A X-Survey GNSS Survey AntennaHX-CSX100A HX-CSX601A GNSS Satellite Tracking AntennaHX-CSX601A HX-CSX078A OEM GNSS AntennaHX-CSX078A
Dimensions
(diameter x height)
152 x 62.2mm 152 x 62.2mm 130 x 22.3 mm 173.4 x 62.6 mm 111 x 24.5 mm
Weight < 500g < 500g < 230g < 500g < 220g
Signals GPS L1/L2/L5/L-Band
GLONASS L1/L2/L3
BDS B1/B2/B3
GALILEO E1/E6/E5a/E5b
QZSS L1/L2/L5/L6
IRNSS L5
SBAS L1/L5
GPS L1/L2/L-Band
GLONASS L1/L2
GALILEO E1
BDS B1/B2/B3
QZSS L1/L2
SBAS L1
GPS L1/L2/L5
GLONASS L1/L2/L3
BDS B1/B2/B3
GALILEO E1/E5a/E5b/E6
L-Band
Bluetooth
Wi-Fi
4G
GPS L1/L2/L5/L-Band
GLONASS L1/L2/L3
BDS B1/B2/B3
GALILEO E1/E6/E5a/E5b
QZSS L1/L2/L5/L6
IRNSS L5
SBAS L1/L5
GPS L1/L2/L5
GLONASS L1/L2
BDS B1/B2/B3
Galileo E1/E5ab/E6
L-band
Peak Gain 5.5 dBi 5.5 dBi 5.5 dBi 6dBi (1164-1300MHz)
5.5dBi (1520-1615MHz)
5.5 dBi
LNA Gain 40 dB 40 dB 40 dB 40 dB 40 dB
LNA Noise < 2 dB < 2 dB < 1.6 dB < 2 dB < 2 dB
Type Rugged IP67 Rugged IP67 OEM Rugged IP67 OEM

More Information: GNSS Survey Antennas

Webinar: Harxon Survey Antennas – Positioning The World, Easy & Efficient

UAV Helix Antennas

Compact GNSS helical antennas

High-precision GNSS Helix antennas for UAVs

Our helix antennas for UAVs are compact, lightweight and easily integrated into a variety of platforms, utilising advanced D-QHA technology for stable performance and highly-reliable low-elevation satellite tracking while maintaining high gain.

The small form factor helix antennas track GPS, GLONASS, GALILEO, and Beidou, and we provide options for L-band and RTK services. The antennas are ideal for a variety of demanding UAV applications, including aerial photography, remote sensing, infrastructure inspection and public security.

Specifications:

HX-CU7006A Embedded GPS Helix AntennaHX-CU7006A
Embedded Helix Antenna
HX-CU7603A GNSS Helix AntennaHX-CU7603A
Helix Antenna
HX-CH7609A GNSS Helix AntennaHX-CH7609A
Helix Antenna
HX-CU7005A Embedded GPS Helix AntennaHX-CU7005A
Embedded Helix Antenna
HX-CH7018A Embedded Helix AntennaHX-CH7018A
Embedded Helix Antenna
HX-CHX600A D-Helix - Dual Quadrifilar Helix AntennaHX-CHX600A
D-Helix™ Antenna
UAV Helix Antenna HX-CH7603AHX-CH7603A
UAV/Helix Antenna
OEM Helix Antenna HX-CH6017AHX-CH6017A
OEM Helix Antenna
HX-CH6601A UAV Helix AntennasHX-CH6601A
UAV/Helix Antenna
HX-CH3602A UAV Helix AntennaHX-CH3602A
UAV/Helix Antenna
HX-CH4601A UAV Helix AntennaHX-CH4601A
UAV/Helix Antenna

More Information: UAV Helix Antennas

Webinar: Harxon Helix & Aviation Antennas Technology in Perspective
