Checklist for Seamless PCB Manufacturing

By Mike Ball / 26 Oct 2021
Follow UST

Printed circuit board assemblySan Francisco Circuits (SFC), a provider of PCB (printed circuit board) fabrication, assembly and test services for unmanned systems and robotic platforms, has released a manufacturing checklist resource designed to minimize mistakes during all stages of bareboard PCB fabrication.

View the full checklist on SFC’s website

The checklist has been put together with the benefit of many years of experience from the SF Circuits team of experts on what has been successful for manufacturing and processing high-quality PCB orders from start to finish. It serves as an excellent starting point to get an accurate estimation for placing an order.

The list includes the following essential elements for successful manufacturing:

  • Type of material
  • Surfaces requiring plating
  • Soldermask requirements
  • Which surface finish will be used
  • Silk screen requirements
  • Vendor UL logo and date code requirements
  • Types of tolerances
  • Fabrication and acceptance guideline requirements
  • Manufacturing files
  • Fabrication specs
  • Bill of materials with part numbers and notes
  • Assembly type

When planning the fabrication of a printed circuit board many things must be planned carefully to minimize mistakes. SFC’s checklist is an essential tool for ensuring a seamless manufacturing process.

To learn more, contact San Francisco Circuits: Visit Website Send Message View Supplier Profile
