UAV Ecosystem Extended for Reliable GNNS Positioning

Robust high-accuracy RTK positioning is now easily accessible to drone integrators thanks to Septentrio’s multiple partners, 3DR, Holybro, ARK Electronics and Systork By Joe Macey / 23 Apr 2024
Follow UST

Septentrio’s work with drone solutions providers 3DR, Holybro, ARK Electronics and Systork is resulting in numerous products that allow easier prototyping or integration of the mosaic™ GNSS receiver into UAVs.

Septentrio Expands UAV Ecosystem for Reliable GNNS Positioning

mosaic is a compact triple-frequency receiver leveraging signals from all available GNSS constellations to achieve the highest degree of positioning availability, even under challenging conditions.

Built-in anti-jamming and anti-spoofing technology protects mosaic against intentional or unintentional interference. Such a high level of positioning robustness is important for applications where safety is a concern, for example for drone-shows and delivery drones.

A high level of positioning reliability is also required by unmanned aerial vehicles which operate in challenging environments such as around high structures, under foliage or in places of possible RF interference.

In addition to collaborations with hardware integrators Septentrio also works closely with the open-source autopilot community including PX4 and Ardupilot to facilitate a smooth integration process for end-users.

Gustavo Lopez, Market Portfolio Manager at Septentrio, said; “We are pleased to see the success of our current partnerships and are open to working with other integrators who are interested in making UAV-specific products with a competitive edge of superior reliability and resilience.

“We are also grateful for the excellent support of the community with their recent updates to PX4 and Ardupilot, which include mosaic features which are essential for UAVs.”

The recently available products that bring reliable high-accuracy positioning to UAVs include Holybro H-RTK mosaic-H (dual antenna heading), 3DR mosaic-X5 CAN GPS, Systork Linnet mosaic-X5 and ARK mosaic-x5 GPS. Such products offer UAV-centered features such as magnetometer, barometer or UAVCAN communication. They also feature the mosaic™ module which receives signals from all GNSS constellations including GPS, GLONASS, Galileo, BeiDou and QZSS and outputs centimeter-level RTK positioning as well as full GNSS carrier raw data.

Dual antenna operation is also supported with mosaic-H for heading and pitch or heading and roll orientation with sub-degree accuracy. Advanced anti-interference technology AIM+ not only protects the system from malicious jamming and spoofing attacks, but also reduces the risk of self-interference which occurs when nearby electronics like cameras and servos accidentally emit radio signals that interfere with GPS/GNSS.
