The Nuvo-9154GC from Neousys Technology is a ruggedized GPU computer designed for autonomous mobile robots operating in warehousing, logistics, and agriculture. It combines Intel® 14th, 13th, or 12th Gen Core™ processing with support for NVIDIA® RTX™ graphics cards up to 150W TDP, providing CPU and GPU resources for multi-camera vision processing, sensor fusion, object recognition, SLAM, and LiDAR-based path planning.
Four onboard GMSL2 camera interfaces provide driver-ready Linux support for selected 2MP to 8MP automotive cameras, while a dedicated porting mode supports integration of unlisted GMSL2 cameras through I2C configuration. GPS PPS input and output are provided for frame synchronization calibration.
For mobile robotic installations, the Nuvo-9154GC provides five 2.5GbE interfaces, one GbE connection, IEEE 802.3at PoE+ on ports 3 through 6, dual CAN 2.0 channels, and USB connectivity including a USB 3.2 Gen2x2 Type-C interface. Expansion sockets support wireless connectivity options including Wi-Fi, 4G LTE, and 5G, alongside M.2 NVMe and dual SATA storage interfaces.
The system accepts an 8V to 48V DC input with integrated ignition control and supports operation down to -25°C, with a maximum operating temperature of up to 60°C depending on CPU power configuration. Mini-FAKRA Z camera connectivity, a dedicated GPU retention bracket, and MIL-STD-810H vibration and shock testing further address the requirements of vibration-prone AMR and vehicle installations.
Specifications:
| Processor: | Intel® 14th/13th/12th Gen Core™ processors, up to 24 cores / 32 threads, 35W or 65W TDP |
| GPU: | NVIDIA® RTX™ series graphics card support up to 150W TDP |
| GMSL2 cameras: | Up to 4 cameras via a 4-port Mini-FAKRA Z connector; selected 2MP to 8MP configurations supported under Linux |
| Networking and vehicle I/O: | 5× 2.5GbE, 1× GbE, PoE+ on ports 3–6, and 2× CAN 2.0 |
| Power & operating temperature: | 8V to 48V DC input with ignition power control; -25°C to 60°C depending on CPU power configuration |
