Prism Mobile is a compact video encoder that delivers reliable real-time video transmission from UAVs, robotic platforms and other mobile assets operating beyond line-of-sight. By bonding up to nine separate network connections across mobile hotspots, Ethernet interfaces and internal and external cellular modems, the system ensures uninterrupted delivery of mission-critical video intelligence even in congested, remote or rapidly changing communications environments. With ultra-low latency performance, it provides operators, command centers and decision-makers with timely situational awareness when every second counts.
Designed specifically for field deployment, Prism Mobile combines a low-profile camera-back form factor with dual internal 5G modems optimized for professional video transmission applications. The platform supports worldwide cellular connectivity and utilizes high-gain antennas to maximize network performance and reliability in demanding operational conditions. Advanced H.264 and H.265 encoding capabilities enable efficient delivery of high-quality video while minimizing bandwidth requirements.
Supporting both CBRS and private 5G networks, Prism Mobile allows organizations to leverage secure, high-availability wireless infrastructure for tactical, public safety and defense operations. For deployments in bandwidth-constrained or infrastructure-limited environments, the platform can also be connected to satellite communications systems such as Starlink through integrated Ethernet and Wi-Fi interfaces, extending operational reach far beyond conventional network coverage.
The versatile solution supports up to 4K60 HDR video transmission and can be configured for a wide range of UAV and mobile surveillance workflows. With latency as low as 80 milliseconds and powerful network bonding capabilities, Prism Mobile enables the reliable distribution of live video intelligence to remote operators and command personnel, improving coordination, situational awareness and decision-making across mission-critical operations.
Specifications:
| Dimensions (W x D x H): | 5.9 x 3.9 x 1.3" (162 x 92 x 35mm) |
| Weight: | 23.4oz (664g) without plates
30.5oz (864g) with plates |
| Input Voltage: | 6 - 28V |
| Power Consumption: | 20W nominal
36W max |
| Video Compression/Decompression: | ISO MPEG-4 Part 10: Advanced Video Coding (AVC)/ITU H.264
AVC: Baseline, Main, High ISO MPEG-H Part 2: High-Efficiency Video Coding (HEVC)/ITU H.265 HEVC: Main |
| Supported Video Bitrate: | 250 Kbps to 85 Mbps with advanced encoder and rate control configuration |
| Supported Resolutions: | 4K DCI p23.98/24/25/29.97/30/50/59.94/60
4K UHD UHD p23.98/24/25/29.97/30/50/59.94/60 1080p 23.98/24/25/29.97/30/50/59.94/60 1080i 50/59.94/60 1080PsF 23/24/25/29/30 720p 50/59.94/60 576i 480i |
| Video Inputs: | 1x 12G/6G/3G/HD/SD-SDI (75 Ω BNC)
1x HDMI 2.0 Type-A receptacle |
| Video Outputs: | 12G/6G/3G/HD/SD-SDI (75 Ω BNC) |
