Njord GNSS Receiver Multi-constellation receiver for marine applications
Njord GNSS Receiver

Multi-constellation receiver for marine applications

Visit Website Contact
Njord GNSS Receiver

The Njord is a multi-frequency, multi-constellation GNSS receiver designed to provide precise positioning and heading for construction as well as marine applications such as USVs. Corrections can be received via L-band, and the Benchmark PPP Service technology provides seamless RTK performance even during connection outages.

The convenient front panel provides status display and configuration capabilities, and communications options include UHF radio, cellular, Wi-Fi, Bluetooth, USB and Ethernet. The receiver features three hours of reserve emergency power, allowing it to enter standby mode if work is interrupted unexpectedly by loss of external power.

Dimensions 203 x 129 x 60mm
Weight 1.25 kg
Power Consumption 4.5W (rover mode)
Signal Tracking BDS: B1/B2/B3
GPS: L1/L2/L5
QZSS: L1/L2/L5
Positioning Accuracy RTK H:± 8 mm + 1 ppm V:± 15 mm + 1 ppm
Static H:± 2.5 mm + 0.5 ppm V:± 5 mm + 0.5 ppm
Autonomous H:±1.5m (RMS) V: ± 3 m (RMS)
SBAS H:±0.5 m (RMS) V: ± 0.85 m (RMS)
Hi-RTP H:±5 cm (RMS) V: ± 10 cm ( RMS)
Heading Accuracy 0.05° @ 4.0 m antenna separation
