AIRLink Telemetry from SAGLAMTEK is a broadband AES-256-encrypted private-channel system built around 2×2 MIMO technology. Its standard configuration operates from 2402 to 2477 MHz with 4 or 8 MHz bandwidth, providing a stated data rate of 25 Mbps with latency below 100 ms. The system supports output power up to 30 dBm / 1 W and a stated direct line-of-sight range of 20 km, with an operating ambient temperature of -40 to +50°C.
The architecture comprises dedicated air and ground modules. The 50 g air module measures 50 × 50 × 30 mm and provides Ethernet connectivity, while the 137 g ground unit measures 82 × 71 × 21 mm and incorporates Ethernet, USB, UART, and power interfaces. Alternative 900 MHz, 2300 MHz, and 2500 MHz frequencies are available, together with 1 W, 5 W, and 20 W output options for range extension. Panel, blade, and high-gain omnidirectional antenna choices are also specified.
| Technology: | 2×2 MIMO |
| Frequency: | 2402–2477 MHz |
| Power: | Up to 30 dBm / 1 W |
| Bandwidth: | 4 / 8 MHz |
| Encryption: | AES-256 |
| Data rate: | 25 Mbps |
| Latency: | <100 ms |
| Range: | 20 km |
| Visibility: | Direct, line of sight |
| Ambient temperature: | -40 to +50°C |
| Air module power input: | 5 V DC, 2 A min |
| Air module antennas: | 2× SMA Omni, 3 dBi, 50 cm cable |
| Air module interfaces: | Ethernet, cooling fan output |
| Air module dimensions: | 50 × 50 × 30 mm |
| Air module weight: | 50 g |
| Ground module power input: | 7–40 V DC, 1 A min |
| Ground module antennas: | 2× RP-SMA, 5 dBi |
| Ground module interfaces: | Ethernet, USB, UART, power supply |
| Ground module dimensions: | 82 × 71 × 21 mm |
| Ground module weight: | 137 g |
| Alternative frequencies: | 900 MHz, 2300 MHz, 2500 MHz |
| Alternative power outputs: | 1 W, 5 W, 20 W |
| Antenna options: | Panel antenna, blade antenna, high-gain omni antenna |
