Full HD EO/IR Camera Gimbal for UAVs Released

Published: 26 Oct 2020 by

UKRspecsystems USG-212 EO-IR gimbal

UKRspecsystems’ UAS Components division has released a new Full HD EO/IR gyro-stabilized gimbal system designed for fixed-wing UAVs (unmanned aerial vehicles). The dual-sensor USG-212 operates both during the day and at night and is equipped with a real-time video processing unit that enables users to keep track of targets while recording digitally stabilized video with up to 30x optical zoom.

Full HD EO/IR UAV Camera GimbalThe rugged unit has been environmentally sealed to prevent damage by rain, snow and other factors, and comes with an anti-vibration damping unit that allows the system to be adapted to various aerial platforms. It is provided in a rugged carry case for easy and secure transportation.

Weighing just 2200g and measuring 266 mm by 160 mm, the compact USG-212 is ideal for SWaP (size, weight and power)-constrained drones.

The gimbal is supplied with intuitive ground control software that allows the user to easily control the gimbal from anywhere within range, receiving real-time video. The drone’s flight path can be plotted on a map, and augmented reality features can be used to add objects and effects onto the map.

Technical specifications of the USG-212 camera gimbal include:

Weight: 2.2 kgs
Power consumption: 36V, 4A
Rotation: Yaw (360 degrees), Pitch (+30 degrees to -90 degrees)
Command system: Compatible with UAS Components’ Pelco-D proprietary protocol and MAVLink (RS-19)
ITAR Free: can be exported to any country

Full HD EO/IR Camera Gimbal for UAS
Full HD EO/IR Drone Camera Gimbal
