Iridium & GPS L1 Antenna

This lightweight and compact hemispherical passive antenna is ideal for providing UAVs and UGVs with access to the Iridium worldwide satellite communication and location service network, enabling two-way voice and data communication from anywhere in the world.

The antenna is also receive-only for GPS L1, providing positioning and timing capabilities for any attached radio system. The rugged IP67-rated unit has been designed with a wide 120-degree hemispherical coverage area to capture as much sky as possible and reduce satellite acquisition time.

Specifications:

Dimensions (D x H) 17.78 x 54.1 mm (0.7 x 2.13 in)
Weight 24.4 g (0.9 oz)
Frequency Range 1 1.565 – 1.585 GHz
Frequency Range 2 1.616 – 1.627 GHz
Impedance 50 ohms
Maximum Gain 2.3 dBic
Horizontal Beamwidth 360°
Vertical Beamwidth 120°
