The DJI Flycart 100 Tether Station is a ground-based power system engineered to convert the Flycart 100 drone into a continuously operating aerial platform for liquid dispersal tasks. By delivering sustained electrical power through a lightweight tether, the system removes reliance on onboard batteries, enabling extended-duration spraying missions without interruption. This configuration is particularly suited to industrial cleaning, firefighting support, and decontamination workflows where persistent aerial coverage is required.
Designed for rapid deployment and stable operation, the tether station integrates with the Flycart 100 platform to maintain consistent lift performance while supporting water or fluid spraying payloads. The system is built to manage power transmission efficiently over altitude while maintaining operational safety and control. Its architecture supports demanding unmanned operations where downtime, battery swaps, and mission resets would otherwise limit productivity.
| Dimensions (D x W x H): | 560 x 460 x 380 mm (ground module) |
| Weight: | 38 kg incl. 110m cable (ground module) |
| Cable Lengths: | 110, 220m |
| Flight Duration: | 24 hrs |
| Ground Module Input Voltage: | 360 – 440 VAC, 50/60 Hz |
| Ground Module Output Voltage: | 700 – 900VDC adjustable |
| Ground Module Output Power: | ≤20,000W (rated long-term output) ≤22,000W (peak, up to 30s) |
| Air Module Input Voltage: | 600 - 900 VDC |
| Air Module Output Voltage: | 58.5 ± 1% VDC |
| Air Module Output Power: | 24,000W (rated long-term output) 28,000W (peak, up to 10s) |
