Triple-Axis Fiber Optic Gyroscopes
Micro-Magic's triple-axis FOG gyroscope products offer robust angular velocity outputs and enhanced precision in robust IP67-rated enclosures with RS-422 digital output. They are ideal for drone and unmanned systems orientation and stability applications, as well as for integration into higher-order systems such as IMUs and INS.
Specifications:
| GF3X80-H/M | GF3X90-H/M | GF3X100-H/M | |
| Dimensions: | Ф80 x 70 mm | Ф90 x 70 mm | Ф100 x 95 mm |
| Weight: | 680g | 780 g | 950g |
| Dynamic Range: | ±500o/s | ±500o/s | ±500o/s |
| Zero Bias Stability: | 0.3 – 0.5o/hr | 0.005 – 0.015o/hr | 0.05 – 0.1o/hr |
| Zero Bias Repeatability: | 0.3 – 0.5o/hr | 0.003o/hr | 0.05 – 0.1o/hr |
| ARW: | 0.5o/√hr | 0.01o/√hr | 0.1o/√hr |
