IPET SYSTEM's N8L is a weather-resistant motor solution for heavy-lift multirotor drones operating in harsh environments, featuring an internal rotor structure with IP66-rated protection. The N8L is designed for quadcopters with takeoff weights of 22 to 25 kg, and is supplied as a motor-only configuration, allowing UAV teams to select the ESC, control protocol, and cooling strategy that best fit the aircraft architecture.
The motor delivers IP66-rated protection as standard (IP67 available on request) and has passed a 120-hour salt spray endurance test, making it suitable for sandy, humid, marine, and corrosive conditions. A three-bearing support architecture controls shaft movement and supports upright or inverted installation for both puller and pusher layouts.
Specifications:
| Propeller: | N30, 30" (recommended) |
| Max Thrust: | 17.5 kg |
| Continuous Power: | 802W (180s) |
| Efficiency: | 8.56 g/W (6.86 kg, 56% throttle) |
| Peak Current: | 80A |
| Weight: | 695g (±2%, inc. cable) |
| ESC: | Not included (motor-only, flexible ESC selection) |
| Recommended Battery: | 12S LiPo |
| IP Rating: | IP66 standard / IP67 optional |
| Operating Temperature: | -25°C to 60°C |
| Motor KV: | 120 |
