The microFLUX 2MP is a compact, NDAA-compliant smart power supply developed by Hargrave Technologies for uncrewed aircraft that require higher current delivery with precise control and real-time visibility. It provides a Western-built, drop-in solution for powering mission-critical avionics and payloads, combining high efficiency with dependable protection and telemetry features. Drawing on more than a decade of UAS power-electronics experience, it ensures reliable power management and easy system integration for professional unmanned platforms.
Engineered for flexibility, microFLUX 2MP features software-configurable outputs that allow rapid adjustment of voltage levels as system requirements change. Integrated data logging, intelligent protection, and status monitoring improve situational awareness and support efficient maintenance workflows. Compact, robust, and built for operational confidence, the microFLUX 2MP delivers high-performance across demanding UAS applications.
Specifications:
| Dimensions: | 21 × 103 × 56.85 mm [0.8 × 4.05 × 2.2 in] |
| Weight: | 118 g [4.16 oz] |
| Power Supply Voltage: | 15–60 V [4S–14S] |
| Outputs: | 2 channels, software-configurable voltage |
| Output Voltage Range: | 3.3 V to 28 V [digitally selectable, 32 levels] |
| Rated Output / Continuous Current: | 20 A per channel |
| Absolute Max Output Current: | 24 A |
| Operating Temperature: | −20 to +50 °C [−4 to 122 °F] |
| CAN Bus Support: | DroneCAN |
