The ViuMesh Pro series is a compact MIMO wireless datalink platform developed for drones and robotic systems requiring extended communication range and multi-node networking. Operating at 1.4 GHz, the series combines mesh networking for as many as 64 nodes with orthogonal frequency division multiplexing (OFDM). Supported modulation schemes include BPSK, QPSK, 16QAM, and 64QAM, while AES-128 and AES-256 encryption provides protection for transmitted data. The range includes multiple configurations spanning different transmission power, physical size, weight, interface, and communication-distance requirements.
ViuMesh Pro models extend from the 0.5 W × 2 Pro 01H, rated for communication distances of 10 km, through the 10 W × 2 Pro 20H, which reaches 200 km. Pro 02H through Pro 20H models provide maximum throughput of 47 Mbps at 20 MHz, while the Pro 01H delivers 2–8 Mbps downlink throughput and 600 kbps uplink throughput. Depending on the model, available connectivity includes MMCX or SMA antenna connections, Ethernet, serial, S.BUS, PWR, SMA-K, and J30J-25P interfaces, supporting integration into varied uncrewed aircraft and robotic platforms.
| Pro 01H | Pro 02H | Pro 04H | Pro 08H | Pro 10H | Pro 14H | Pro 20H | |
| Frequency | 1.4 GHz | 1.4 GHz | 1.4 GHz | 1.4 GHz | 1.4 GHz | 1.4 GHz | 1.4 GHz |
| Transmission power | 0.5W × 2 | 1W × 2 | 2W × 2 | 4W × 2 | 5W × 2 | 7W × 2 | 10W × 2 |
| Throughput | 2–8Mbps downlink; 600kbps uplink | 47Mbps max @20MHz | 47Mbps max @20MHz | 47Mbps max @20MHz | 47Mbps max @20MHz | 47Mbps max @ 0MHz | 47Mbps max @ 0MHz |
| Maximum mesh nodes | Up to 64 | 64 | 64 | 64 | 64 | 64 | 64 |
| Input voltage | DC 12–30V @1A; 12V recommended |
DC 12–36V | DC 12–36V | DC 18–30V | DC 12–36V | DC 12–36V | DC 21–27V; typical 24V @5A |
| Dimensions (mm) | 57.5×55×16 passive cooling; 57.7×49.9×16.8 active cooling | 100 × 62 × 20 | 100 × 62 × 20 | 109.7 × 93.3 × 24 | 138 × 62 × 27 | 150 × 62 × 30 | 183.5 × 109.3 × 29.5 |
| Weight | 91g passive cooling; 70g active cooling | 160g | 160g | 355g | 225g | 500g | 680g |
| Interfaces | MMCX, PWR, ETH*, Serial, S.BUS | SMA, ETH, Serial, S.BUS, PWR | SMA, ETH, Serial, S.BUS, PWR | SMA-K, J30J-25P | SMA, ETH, Serial, S.BUS, PWR | SMA, ETH, Serial, S.BUS, PWR | SMA-K, J30J-25P |
| Operating temperature (°C) | -30 to +55 | -40 to +55 | -40 to +55 | -40 to +55 | -40 to +55 | -40 to +55 | -30 to +55 |
| Communication distance | 10 km | 20 km | 30 km | 50 km | 100 km | 150 km | 200 km |
