Orqa FPV.One Pilot
Orqa's FPV.One Pilot is a set of NDAA-compliant analog FPV goggles with two 0.5 in OLED displays. The screens provide 1,280 × 960 px resolution, with a 37-degree viewing angle at 4:3 or 33 degrees at 16:9.
The built-in DVR records H.264 video at 1,280 × 960 px and 50 or 60 fps. The goggles include a RapidFire-compatible analog receiver bay, micro HDMI input, 3.5 mm head-tracker output, and a secondary 5 V expansion bay with SDIO and UART. Optical adjustment covers focus from -4D to +4D and interpupillary distance from 56 to 74 mm. They accept 6 to 25 V DC power and incorporate overvoltage and reverse-polarity protection.
Specifications:
| Display Size | 2 × 0.5 in |
|---|---|
| Screen Resolution | 1,280 × 960 px |
| Viewing Angle | 37° at 4:3; 33° at 16:9 |
| Power Supply | 6 to 25 V DC (2S to 6S) |
| Power Consumption | 2.8 W typical |
| Focus Adjustment | -4D to +4D |
| IPD Range | 56 to 74 mm |
| DVR Resolution And Rate | 1,280 × 960 px at 50 or 60 fps |
| Weight Without Battery | 259 g |
| Packaged Weight | 560 g |
| Dimensions | 177 × 107 × 72 mm |
