Airbot Mini Power Brick 100A
Airbot's Mini Power Brick 100A is a power-management component for UAV electrical systems, providing regulated power for the flight controller as well as information on battery voltage and current consumption through built-in sensing. Voltage and current information is used to determine power consumption and estimate remaining battery capacity, allowing the flight controller to provide failsafe warnings and take other actions in the event of low power.
The unit incorporates a high-quality switching voltage regulator that supports up to 12S input and provides 3 A continuous output. Lightweight and compact, it can be installed in virtually any UAV platform.
Specifications:
| Dimensions | 44 × 27 × 17.6 mm |
|---|---|
| Mounting Hole Diameter | M3 |
| Mounting Hole Spacing | 38 mm |
| Weight | 31 g |
| Maximum Input Voltage | 12S |
| Maximum Output Current | 3 A |
| Peak Output Current | 4 A |
| Maximum Measured Current | 100 A |
