The Ruyi is a protocol-level counter-UAS system that enables authorized operators to assume control of unauthorized drones through CRPC® 3.0 (Cognitive Radio Protocol Cracking) technology. By performing deep-layer parsing of supported drone control protocols and reconstructing control-layer data streams, the system enables flight take-over or forced propeller stop without relying on conventional RF jamming techniques. Designed for fixed-site deployment, the Ruyi provides a non-kinetic approach to drone threat mitigation for environments where minimizing collateral effects is critical.
Supporting a wide range of mainstream radio-control protocols, including ELRS, TBS, FrSky, Flysky, Futaba, Radiolink, and BETAFPV, the system offers two response modes: controlled flight take-over and forced propeller stop. When integrated with LZ Tech detection platforms, the Ruyi forms a closed-loop “detect and seize” architecture that streamlines the transition from target identification to electronic intervention. Operating continuously with IP66 environmental protection, the system is suited to critical infrastructure protection, airports, government facilities, industrial sites, border security operations, and other locations requiring advanced counter-drone capabilities without the risks associated with kinetic mitigation methods.
Specifications:
| Dimensions: | 370 × 335 × 247 mm (antennas excluded) |
| Supported Protocols: | ELRS 868M/915M/2.4G TBS 868M/915M/2.4G FrSky X9D2 BETAFPV Cetus Radiolink T8FB Flysky FS-i6 Futaba T14SG |
| Key Frequency Bands: | 868 MHz 915 MHz 2.4 GHz |
| Take-Over Range: | Visual line of sight |
| Countermeasure Modes: | Flight take-over or forced propeller stop |
