The Vision4ce CHARM150AGX is a standalone video processing board for embedded video and image processing applications. Based on the NVIDIA AGX Orin platform, it incorporates a multicore Arm processor alongside a powerful AI/ML accelerator. Designed to host Vision4ce’s FrameWorkx image processing software, which builds upon the field-proven DART video tracking software, the board supports image processing functions with integrated tracking capability.
The unit supports two SDI video inputs and outputs across SD, HD, and 3G formats, with video resolutions ranging from standard definition to 1080p. Optional mezzanine expansion enables additional interfaces including Camera Link, CoaXPress, analog video, and further SDI inputs. A range of data interfaces is provided, including Ethernet, USB 3.0, serial RS422, CAN bus, IRIG DCLS, and GPIO. The board also includes an M.2 expansion slot, operates from a 12V DC supply at under 80W, and is specified for operation across extended temperature, humidity, and shock conditions.
| Processor: | NVIDIA AGX Orin with Arm CPU and AI/ML acceleration |
| Video inputs: | 2x SD/HD/3G-SDI |
| Video outputs: | 2x SD/HD/3G-SDI with overlay support |
| Data interfaces: | Ethernet, USB 3.0, RS422, CAN bus, IRIG DCLS, GPIO |
| Expansion: | M.2 slot (Key M), mezzanine video interface options |
| Power: | 12V DC, <80W |
| Dimensions: | 150 x 120 x 37 mm |
| Operating temperature: | -40°C to +71°C |
