SPx Fusion Server

SPx Fusion Server software fuses observations from multiple primary radar videos and secondary sources such as AIS, IFF and ADS-B into a single stream of correlated reports that can be broadcast over a network with no additional development required.

The SPx Fusion software allows users to assign a priority and a score to each sensor, giving more weight to sensors which are known to be more accurate. The radar software correlates the input source reports and generates a single set of output reports without duplicates. It supports sensors in different geographic locations that have overlapping coverage regions, e.g. an S-band and X-band radar, providing handover support as targets move from one sensor to the next.

SPx Fusion Server is designed to run on standard Intel PC or SBC hardware under Windows or Linux. SPx Fusion is also available as a software development library that allows users to quickly and easily add fusion capability to their own C2 applications.
