UAV SATCOM for BVLOS Communication
PLANET 9523 UAV Terminal Combined UAV SATCOM & cellular modem
PLANET 9523 UAV Terminal

Combined UAV SATCOM & cellular modem

Visit Website Send Message
Saved
Save
PLANET 9523 UAV Terminal

The PLANET 9523 is a lightweight mobile data communications terminal that can take advantage of both Iridium SATCOM services and terrestrial cellular networks. Acting as a universal mobile router, the unit provides critical connectivity and real-time data exchange for autonomous and BVLOS UAVs and is also ideal for ground-based and marine platforms such as UGVs and USVs.

The terminal can communicate with external equipment via Ethernet, serial, or an optional Wi-Fi module, and includes an integrated GNSS receiver for autonomous location and timing as well as 128 GB of SD card memory. A variant without LTE is also available.

Specifications:

Dimensions (W x D x H) 180 x 100 x 30 mm
Weight 260g
Power Consumption Average 700mA @ 12VDC
Peak 4.5A @ 12VDC / 6A @ 9VDC
Power Supply 9 - 36VDC
Operating Temperature 0° to +50°C
