Double-Balanced RF Mixers
Asartech’s PZ0227 and PZ0228 double-balanced mixers provide frequency upconversion and downconversion for microwave transceivers, radar and point-to-point communications equipment. Their different RF, LO and IF ranges offer a choice of frequency-conversion configurations.
PZ0227 covers RF frequencies from 3 to 13 GHz, and PZ0228 extends coverage to 19 GHz with a wider LO and IF range. Both modules provide RF return loss greater than 9 dB and LO input return loss greater than 10 dB, and are suitable for test equipment.
Specifications:
Both models operate from a 6–7.5 V supply.
