MIL-I-46058C Certification for Dymax 9771 Conformal Coating

The MIL-I-46058C standard establishes conformal coating compliance requirements and evaluates them to an extensive list of properties, including curing time and temperature, material thickness, and moisture resistance By Joe Macey / 12 Sep 2023

Discover World-Leading Unmanned and Autonomous Technologies

Discover cutting-edge solutions from leading global suppliers
SUPPLIER SPOTLIGHT
Dymax 9771 conformal coating is designed for satellite, spacecraft, and critical PCB assembly applications
Dymax 9771 conformal coating is designed for satellite, spacecraft, and critical PCB assembly applications.
Follow UST

Dymax AR conformal coating, 9771, has completed the rigorous qualification testing for Military Specification MIL-I-46058C.

This UL94V0 and UL746E recognized dual-cure coating has also been approved to the IPC- CC-830B standard and fully complies with RoHS2 Directive 2015/863/EU.

The MIL-I-46058C standard establishes conformal coating compliance requirements and evaluates them to an extensive list of properties, including curing time and temperature, material thickness, moisture resistance, fungus resistance, insulation resistance, flexibility, hydrolytic stability, and flame resistance. 9771 is now listed in the DOD QPL (Qualified Products Listing) database so military manufacturers know it is approved.

Along with this important recognition, 9771 coating passes NASA Low Outgassing ASTM E595 specification for cleaner PCBs during extreme conditions and meets low-ionic content compliance with Mil-Std 883 Method 5011. Additionally, 9771 is NASA MAPTIS listed and assigned material number 09841, so suppliers searching for low-outgassing coatings can easily find it in the database.

Dymax 9771 conformal coating is 100% solids with a blue fluorescent tracer. This high-performance, dual-cure reworkable conformal coating cures with UV/Visible light and moisture in shadow areas.
