Rugged Tactical Switch and Router for Military Applications Released

By Mike Ball / 31 Jan 2019

OnTime Networks rugged switchOnTime Networks and Architecture Technology Corporation (ATCorp) have announced the introduction of the combination of the new ultra-rugged military grade CR-6228 28-port switch and the NIAP certified CRR-1000-5 High-Performance VPN Router Package. The systems are ideal for secure tactical applications such as military unmanned aerial vehicles (UAVS) and other unmanned platforms.

The new high-performance CR-6228 Series is designed to provide a 28-port intelligent switch and secure software router system for tactical networks in a fully rugged, conduction-cooled, IP68 sealed system, operating from -40°C to +71°C. The military CR-6228 NIAP certified router and gateway supports copper and optical interfaces. With its modular and highly configurable architecture the unit can be tailored to specific client needs, to provide highly secure data, voice, and video communications to stationary and mobile network nodes across wired and wireless links. The CR-6228 has been designed for applications with the most severe Size, Weight, and Power (SWaP) constraints, deployed in the harshest environments.

The ATCorp CRR-1000-5 High-Performance VPN Routing and Encryption Suite is optimized for environments where link performance depends upon radio signal strength. The CRR-1000 creates a flexible mesh network from heterogeneous radios and supports NIAP, CSfC, and Common Criteria (CC) certification.

CRR-1000-5 Features include:

Automatic GRE tunnel establishment

  • Cut-through routing to eliminate encapsulation overhead
  • Dynamic link sensing forwards data along the best path
  • Interoperable with legacy routing equipment

Protocols

  • OSPF (v2&v3), RIP, RIPng, ISIS, BGP, PIM, LDP, IKEv2

Supported Waveforms

  • ANW2, CDL, ROVER, SRW, TTNT
  • LTE, WiFi, MIMO, TSM, Wave Relay
  • Other IP-enabled waveforms

IA Conformance

  • NIAP Network Devices, v2.0
  • NIAP VPN Gateway, Version 2.1

The CR-6228 28-port switch coupled with the CRR-1000 Router package not only combines the latest hardware and software in a SWaP optimized packaging, but also features a high degree of modularity (mix and match functionality), which is highly suited to addressing Department of Defense (DoD) program needs.

Jordan Bonney, Technical Director of Architecture Technology Corporation commented, “The CRR-1000 High-Performance VPN Routing and Encryption Suite powered by the CR-6228 provides a unique tactical network solution for the modern warfighter that’s optimized for aerial-layer networking. The CR-6228 was successfully flight tested as part of Hanscom, AFB’s MACHETE program, where it served as the integration router that seamlessly moved data across COTS and military waveforms and provided NSA-level data-in-transit protection.”

The integrated GbE/10GbE switch provides a total of 28 Ethernet ports, of which 24 ports are 10/100/1000 BASE-T ports and 4 ports are 10/100/1000 BASE-T or SR. The CR-6228 Series enables secure managed network routing and GbE switching capabilities for onboard communications and computing subsystems. The unit is specifically designed to provide reliable, high-performance connectivity for extremely demanding SWaP constraints in harsh demanding environments (e.g. high altitude, extreme shock & vibration, extended temperatures, humidity, dust & water exposure, noisy EMI, dirty power).

Its modular rugged design, enclosed in a completely sealed housing against dust and water ingress (IP68), requires no active cooling and provides MIL-DTL-38999 connectors. The unit features a military-grade power supply for aircraft (MIL-STD-704F) and ground (MIL-STD-1275D) vehicle use, as well as MIL-STD-461F EMI/EMC filtering.

The CM/CR-6228 Series router implementation is based on a separate router board with an Intel Atom processor and can either be equipped with the OnTime Networks router package providing routing speeds of up to 800Mbps or with the Cisco 5921 Embedded Services Router (ESR) Advanced Enterprise router package, or the Architecture Technology Corp. (ATC) Routing and Encryption Suite (ARES) with NIAP, CSfC, and Common Criteria (CC) certification.

Its modular, rugged design, enclosed in a completely sealed housing against dust and water ingress (IP68), requires no active cooling and provides MIL-DTL-38999 connectors. The unit features a military-grade power supply for aircraft (MIL-STD-704F) and ground (MIL-STD-1275D) vehicle use, as well as MIL-STD-461F EMI/EMC filtering.
