Selecting Nano Interconnects for Unmanned Systems Applications

By Mike Ball / 21 May 2018
Follow UST

Ulti-Mate Nano-connectorsUlti-Mate Connector, a provider of miniature connectors and interconnect solutions, has released a whitepaper outlining factors for consideration when integrating nano interconnects into miniature electronics designs such as those found in small unmanned aerial systems (sUAS) and other unmanned vehicles.

Download the full whitepaper from Ulti-Mate’s website

The paper summarizes key considerations when choosing the right board-level Nano connector on a 0.025” pitch, such as:

  • Through-Hole vs Surface-Mount Termination
  • Packaging and Processing Surface-Mount Nano Connectors
  • The Connector /Printed Circuit Board Interface
  • Creating a Reliable Surface-Mount Solder Joint
  • Flat Leads vs Round Leads

Choosing the right interconnect solution is critical for successful design of modern rugged electronic systems and subsystems. To find out more, download the whitepaper from Ulti-Mate’s website.

Find suppliers of Connectors for unmanned applications >
