Silicon Designs Launches Low-Cost USB-Powered DAQ System with FFT Analysis and Display

By Caroline Rees / 14 Mar 2013
Follow UST

Model 3330 G-Logger Data Acquisition SystemSilicon Designs, Inc., (SDI) a global industry leader in the design and manufacture of highly rugged industrial-grade MEMS capacitive accelerometer chips and modules, today announced the global market launch of its Model 3330 G-Logger, a low-cost, USB-powered portable data acquisition system with the same powerful FFT analysis and display capabilities typically found in much more expensive systems.

The three-channel Model 3330 is designed to optimize the low-noise performance characteristics of all Silicon Designs single and triaxial MEMS variable capacitance accelerometer modules with analog output and 8-32 VDC excitation. The G-Logger offers 16-bit data acquisition, with data rates of 1 to 10k samples per second and per axis, through each of its available input channels. The G-Logger’s simple and intuitive user interface is built on an NI LabVIEW® platform for ease of customer use. Model 3330 also features real-time data acquisition and readout capabilities with live streaming; real-time pause, scroll back and rewind; SD-card recording of up to 32 GB, multi-speed recording playback; and remote operation via TCP. Average system setup time is less than five minutes

Optional offset settings allow for a staggered display without overlap. An additional independent scale G/Div is available per channel, with settings that can shrink or expand channel input for better visibility. Data output is displayed over a time range from 100 ms to two minutes. The Model 3330 data page allows for simple G readings, with as-needed real-time ability to hide or show any or all of the three measurement channels. Users may view accelerometer performance data from any remote network location.

Each G-Logger is shipped preconfigured with all necessary Silicon Designs accelerometer specifications, along with accompanying software. As a USB-powered device, additional accelerometer power is not required. Units occupy a highly compact footprint, measuring just 120 mm x 103 mm x 30 mm. Software is fully compatible with Windows XP, Vista, 7, & 8 PCs, laptops, and notebooks.
