The ATC 3750 AI-driven vehicle computer from NEXCOM is a powerful and compact embedded system on module (SoM) solution, designed for inference workloads in applications like collision avoidance for mining or rolling stock.
The ATC 3750 is equipped with the NVIDIA® Jetson AGX Orin™, an AI inference accelerator that is optimized for high-performance and low-power edge computing applications.
The system can deliver up to 200/275 TOPS of processing power, making it ideal for high-performance computing and AI operations.
The ATC 3750 offers six GbE PoE+ ports, along with an optional 10GbE port for high-speed data transmission, providing a surround view of up to six IP CAMs/LiDAR sensors.
Equipped with an AI inference accelerator and strong decoding ability, it delivers up to 7 x 4K30 performance, allowing for precise AI inference and rapid response times to maximize safety.
The embedded device supports SAE Level-2 and Level-3 autonomous driving in fixed mining areas and rolling stock applications. It enhances mining operations by providing rough terrain recognition, detecting drivers’ physiological states, and utilizing ADAS for real-time obstacle detection, thereby increasing both efficiency and safety.
Hybrid Cooling System
Despite its high computing power, the ATC 3750 generates up to 60 watts of heat. It uses a hybrid cooling solution with a pre-installed heat sink and fan to manage this heat, ensuring reliability for heavy-duty applications. For simpler applications, the fan may not be necessary.
Models & Applications
The ATC 3750 is available in two models:
- ATC 3750-6C: Features six RJ45 PoEs and is E-mark certified for mining operations.
- ATC 3750-A6CR: Includes six X-coded PoEs, is EN50155 certified, and offers an optional VTK-PWA20-01 external 24VDC power kit with isolation for enhanced reliability and safety in rolling stock applications.
The ATC 3750 is adaptable and efficient, suitable for a variety of industrial applications due to its broad temperature range, GNSS, LTE/5G NR, Wi-Fi 5/6 expansion capabilities, and NVMe SSD storage.
Equipped with the NVIDIA Jetson AGX Orin AI inference accelerator, the ATC 3750 provides a cost-effective solution for industrial applications such as mining, rolling stock, agriculture, and logistics.
Its certifications, expandability, and high computing power make it an ideal choice for users seeking a versatile and efficient AI solution.
Key Features of the ATC 3750:
- Built-in NVIDIA Jetson AGX Orin SoM, up to 200/275 TOPS (INT8) performance
- Designed with rugged, compact and hybrid cooling solutions
- ATC 3750-6C: 6-port GbE PoE+ for IP CAM/LiDAR sensors, optional 1-port 10GbE
- ATC 3750-A6CR: 6-port GbE PoE+ (X-coded) for IP CAM/LiDAR sensors, optional 1-port 10GbE (X-coded)
- HEVC/H.265 hardware DECODE up to 7 x 4K30 performance
- Wide range operating temperature of -20°C~70°C
- Ultra-speed PCIe 4.0 x4 NVMe SSD for data integrity
- Expansible for GNSS, LTE/5G NR & Wi-Fi 5/6
- ATC 3750-6C: 9~36V DC-IN with ignition control & OCP/OVP
- ATC 3750-A6CR: 24V DC-IN for rail, ignition control & OCP/OVP
- Military standard of MIL-STD-810H for anti-vibration/shock
- ATC 3750-6C: CE/FCC, UKCA, E-mark Certified
- ATC 2750-A6CR: EN50155 (EN55011, EN50121-3-2, EN61373, OT4) Certified
