ANELLO Evaluation Kit
The ANELLO GNSS-INS evaluation kit (EVK) allows developers and system integrators to explore the capabilities of ANELLO’s advanced SiPhOG© (Silicon Photonics Optical Gyroscope) inertial technology. Providing sustained centimeter-level accuracy in conditions such as extended temperature ranges and extreme vibration where more expensive reference-grade systems degrade, the kit is ideal for demanding ground robotics, autonomous vehicle and ADAS applications.
The kit provides everything you need to get started, including two dual band GNSS antennas and all required cables, and offers Ethernet, CAN, USB and serial interfaces for easy integration.
Specifications:
| Dimensions: | 4.2 x 1.5 x 5” |
| Weight: | 1 lbs |
| Power: | 8-30 VDC, 4W typical |
| Gyro Range: | 200°/s |
| Gyro Bias Instability: | < 0.5°/hr |
| ARW: | < 0.05°/√hr |
| Accel Range: | 4g |
| Accel Bias Instability: | 20μg |
| VRW: | 0.03 m/s/√hr |
| Positioning Accuracy: |
SPS: 1.2 m cep RTK: 0.02 m cep 60s GNSS Outage: < 1.0 m RMS |
| Velocity Accuracy: | 0.01 m/s RMS |
| Heading Accuracy: | 0.2o RMS |
| Pitch/Roll Accuracy: | 0.02o RMS |
| GNSS Signals: | L1 C/A, L2C, L1OF, L2OF, B1I, B2I, E1, E5b and SBAS |
