EDOMON
EDOMON is an advanced VTOL fixed-wing UAS designed for long-range and wide-area defense, security and law enforcement applications such as intelligence, surveillance and reconnaissance. Able to stay airborne for up to 10 hours and cover up to 100 km in a single flight, it features a modular payload bay and can be equipped with multiple sensors including EO/IR gimbals, IMSI catchers, and AIS receivers.
The aircraft combines the maneuverability of VTOL platforms with the range and efficiency of fixed-wing flight, and utilizes a hybrid propulsion system consisting of a gasoline engine with built-in generator for continuous in-flight battery charging.
Specifications:
| Dimensions: | 1842 x 2717 mm |
| Max Payload Capacity: | 5 kg |
| MTOW: | 23 kg |
| Endurance: | 7 – 10 hrs (depending on configuration) |
| Telemetry & Video Range: | 100 km LOS (extendable) |
| Flight Ceiling: | 14,000 ft |
| Communications Frequency: |
2.4 GHz AES-128 & 256 encryption |
| Max Wind Conditions: |
Takeoff/landing: 50 km/h | 13 m/s (6 Bft) Cruise: 61 km/h | 16 m/s (7 Bft) |
