Neousys Technology has unveiled the PCIe-NPL54, a cost-effective, wide-temperature GMSL2 frame grabber card designed for integration with x86-based edge AI platforms.
Supporting up to four automotive GMSL2 cameras, the PCIe-NPL54 delivers reliable high-resolution video input with low power consumption, making it suitable for autonomous driving, ADAS, and outdoor robotics.
The PCIe-NPL54 enables native integration of GMSL2 cameras with x86 systems, bridging the gap for platforms that lack native MIPI support. It supports up to four 5MP GMSL2 cameras at 30 FPS and is driver-ready for selected automotive cameras featuring HDR (120–140 dB) and LED Flicker Mitigation (LFM). These cameras, widely used in automotive environments, also feature compact form factors and robust FAKRA connectors with coaxial cabling for simplified deployment.
With a fanless design and power consumption of less than 20W under full camera load, the PCIe-NPL54 is suited for power-constrained environments. It operates within a wide temperature range of -40°C to 70°C, making it reliable for outdoor and vehicle-based edge applications. Its single-slot PCIe Gen2 x4 form factor supports easy integration into compact systems, while the integrated power design draws power directly from the PCIe bus. No external power connector is required.
The PCIe-NPL54 also includes a GPS PPS input/output to enable frame-level synchronization across multiple units and other sensors such as LiDAR, ensuring precise alignment for sensor fusion. In addition, an automatic retry mechanism restores the GMSL2 link after disconnections caused by electrostatic discharge (ESD), enhancing system reliability in harsh conditions.
Combining native GMSL2 support, low power consumption, and rugged performance, the PCIe-NPL54 provides a dependable solution for edge AI applications ranging from autonomous systems and mobile robots to smart infrastructure and industrial inspection.
