Advanced Navigation Launches New Digital FOG INS

The D70 is the latest release in the Boreas Digital FOG series and is designed for surveying, mapping, and navigation across subsea, marine, land and air applications By Caroline Rees / 20 Oct 2022
Boreas D70
Follow UST

Advanced Navigation has announced the release of Boreas D70, a new Fiber-Optic Gyroscope (FOG) Inertial Navigation System (INS) that offers a new performance grade with superior accuracy, exceptional stability and reliability.

The D70 is the latest release in the Boreas Digital FOG (DFOG) series and is designed for surveying, mapping, and navigation across subsea, marine, land and air applications.

“We are thrilled to expand the Boreas series with the D70. It’s a system that will provide additional flexibility in the Boreas family, making ultra-high accuracy inertial navigation far more affordable than previous FOG INS systems,” said Xavier Orr, CEO and co-founder of Advanced Navigation. “This patented technology opens the possibility for adopting FOG INS systems across a much broader range of vehicular applications, particularly autonomous vehicles and aircraft, where weight and size are at a premium.”

Advanced Navigation’s Boreas D70 combines cutting-edge closed-loop DFOG and accelerometer technologies with a dual antenna RTK GNSS receiver. These are coupled with the company’s AI-based fusion algorithm to deliver accurate and precise navigation.

The system features ultra-fast gyro compassing, acquiring and maintaining an accurate heading under the most demanding conditions. While D70 does contain a GNSS receiver, it’s not required for gyrocompass operation.

According to Advanced Navigation, the D70 delivers a 40% reduction in Size, Weight, Power and Cost (SWaP-C), when compared to systems of similar performance:

  • 0.01° roll and pitch
  • 0.1° secant latitude heading (gyrocompass)
  • 0.01° /hour bias instability
  • 10mm position accuracy

The Boreas Series

The Boreas DFOG series features ultra-fast gyro compassing and can acquire heading, either stationary or dynamically, in under two minutes. The gyro compassing allows the system to determine a highly accurate heading without any reliance on magnetic heading or GNSS.

The technology stems from Advanced Navigation’s AI sensor fusion algorithm allowing the system to extract significantly more information from the data. It is designed for control applications, with a high level of health monitoring and instability prevention to ensure stable and reliable data.

Advanced Navigation designed Boreas from the ground up for reliability and availability. The hardware and software are designed and tested to international safety standards and have been environmentally tested to MIL-STD-810. The system achieves a mean time between failure of over 70,000 hours.

Additional features of the Boreas D70 include Ethernet, CAN and NMEA protocols, as well as disciplined timing via a PTP server and 1PPS. A rich, responsive embedded web interface provides full access to all of the device’s internal functions and data. Internal storage allows for up to one year of data logging.

About DFOG technology

DFOG is patented technology, which has been developed over 25 years involving two research institutions. DFOG was created to meet the demand for smaller and more cost-effective FOGs, while increasing reliability and accuracy.

Distinguished Professor Arnan Mitchell, the Director of the Integrated Photonics and Applications Center at RMIT University, was a key partner in developing DFOG technology with Advanced Navigation. Professor Mitchell is a noted authority on microtechnology and nanotechnology whose work on shrinking components of a fiber optic gyroscope onto a single chip proved to be one of the key components of DFOG’s revolutionary technology. This innovation is what allows DFOG to have a significantly lower SWaP-C than other similar FOGs, all the while delivering higher accuracy and reliability.

“By printing optical components onto a tiny chip, we are creating more compact and reliable fiber optic gyroscopes with Advanced Navigation,” Professor Mitchell explained.
