NEXCOM’s VMC 320 and VMC 3030 are 10.1-inch all-in-one rugged vehicle mount computers.
The computers boast IP65, IK08 ratings and a 1,000-nit LCD panel for optimal readability in sunlight.
Featuring ARM and x86 system architectures, respectively, developers can choose flexibility and Linux freedom with VMC 320, or optimize Windows/Linux compatibility with VMC 3030’s Atom heart. Additionally, VMC 320 and VMC 3030 support a wide range of power inputs (9VDC~60VDC), enabling flexible installation, making them suitable for various vehicles such as buses, police cars, and forklifts.
NEXCOM VMC 320 and VMC 3030 excel as versatile and reliable rugged vehicle mount computers for public transportation. Their extensive I/O options, including three USB ports, Ethernet connections, and HDMI outputs, ensure seamless connectivity with a wide range of devices and systems, delivering exceptional intelligence, compatibility, and interoperability.
Linux Freedom vs. Windows Efficiency: Choose Your Embedded Development Path
VMC 320 is powered by a NXP i.MX 8M Quad Plus, featuring Arm Cortex®-A53 architecture. It is optimized for fanless operation with Linux platform, a free and open-source operating system, providing more flexibility and customization options for developers. Meanwhile, VMC 3030 is powered by an Intel Atom® x7433RE, 4 Core, 1.5GHz processor with Windows/Linux platform. a robust ecosystem that offers unmatched hardware and software compatibility. This empowers developers to streamline development time.
Wide-ranging Applications Empowered by a Rugged Vehicle Computer
Designed for versatility and compatibility across diverse vehicles, including cars (12 VDC) and forklifts (48 VDC), the VMC 320/VMC 3030 vehicle mount computer supports a broad voltage range of 9 to 60 VDC. An optional battery provides up to 70 (VMC 320)/ 30 (VMC 3030) minutes of internal power under system power consumption 9W (VMC 320)/ 20W (VMC 3030), perfect for forklifts when switching batteries to prevent downtime. Built to endure, the VMC 320/VMC 3030 boasts an IP65 and IK08 rated front panel.
Boost Passenger Engagement with a Second Display
The VMC 320 and VMC 3030 are the perfect choices for seamlessly setting up displays and Passenger Infotainment Systems (PIS) in any vehicle. Enhance the passenger experience with an additional HDMI output for a second display. Providing information about points of interest. Passengers can enjoy local entertainment, news, and weather reports while discovering nearby attractions through collaborations with local tourist bureaus. This enriches their journey and creates opportunities for targeted advertising.
Main Features
- 10.1″ TFT LCD monitor with projected capacitive touch screen
- Wide viewing angle with high resolution 1280 x 800
- Touch panel cover thickness 3mm for IK08 protection
- 1,000nits brightness with sunlight readable capability
- Built-in NXP i.MX 8M Plus low-power processor, 4-core
- Built-in Intel Atom® x7433RE processor, 4-core (VMC 3030)
- HDMI output for 2nd display
- On screen F1 ~ F5 programmable function keys
- Wide range DC input 9V ~ 60V
- Front panel IP65 rating
- Optional back-up battery available
