Ranger-LR Lite – long-range Laser Scanner
The Ranger-LR Lite is a lightweight long-range airborne laser scanner designed for fixed-wing, multirotor and helicopter drone platforms, as well as mobile mapping and backpack systems. The high-density scanner features a powerful 1550 nm laser that penetrates dense vegetation at high speeds and altitudes in large scan regions.
The Ranger-LR Lite includes Phoenix LiDAR’s AIR NavBox, a lightweight rover that allows configuration of heavier payloads for the DJI M600 series and integration of the highest resolution cameras on the market.
- Weight: 4.15 kg
- Dimensions: 32.9 x 16.3 x 17.9 cm
- Absolute Accuracy: 1.5 - 3.0 cm RMSEz @ 120 m Range
- Max Range: 1,000 m at 20% reflectivity, 50 kHz PRR
- Max Scan Rate: 1,500k shots/s, up to 5 returns
