Noxcore HD MWIR Camera Core
The NoxCore HD is a high-performance MWIR infrared camera core designed to provide unmatched surveillance and security capabilities for drones and unmanned vehicles. Featuring a larger field of view for enhanced situational awareness, it can be seamlessly integrated into a wide variety of platforms.
Equipped with state-of-the-art thermal detection, powerful video processing, and Stirling engine cooling technologies, NoxCore HD provides a range of standard video and control interfaces.
Specifications:
| Power Consumption | <20W continuous operation |
| Spectral Range | MWIR 3 to 5μm |
| Video Output |
Color HDMI 720p with color overlay Optional SDI or Analog |
| Matrix Size | 1280 x 720 |
| Pitch | 10 μm |
| Video Streaming |
h.264: RTSP or UDP RAW: GigEVision |
| Optical Aperture | f/4 |
