OptoWOM-II Optically Enhanced Weapon Aiming System

Optically Enhanced Weapon Aiming System

Visit Website Send Message

The OptoWOM-II is a hybrid weapons orientation solution that combines inertial sensors with optical referencing, providing robust and reliable motion tracking and eliminating the errors inherent to traditional digital magnetic compass technology.

The sensor can be mounted directly to a device and operated immediately without any magnetic calibration. OptoWOM-II is IP67-rated and has been tested to MIL-STD-810F, MIL-STD-461D and DO-160D standards.

Output Signals Azimuth (deflection), Pitch & Roll (elevation), Accelerations, Angular Rates
Azimuth Accuracy < 3 mils, RMS
Pitch & Roll Accuracy 1.7 mils, RMS
Size (mm) 136.5 × 67.2 × 110.5
Weight (gram) 570
Applications Optically-Stabilized Weapon Aiming Systems, Day and Night Fire Control Systems, Remote Weapons Stations (RWS)
