miniAHRS Miniature low-SWaP AHRS for air, sea and land applications

Miniature low-SWaP AHRS for air, sea and land applications

Visit Website Contact

The miniAHRS is a lightweight and compact attitude and heading solution that combines three axes of precision accelerometers, gyroscopes and fluxgate magnetometers with state-of-the-art sensor fusion to deliver robust high-accuracy heading, pitch and roll data for both static and dynamic applications.

The system features specialized algorithms tailored to the differing motions of land, air and marine vehicle platforms, as well as gimbals and antennas. All sensing elements are fully calibrated over the entire operational temperature range for superior performance.

Key features and functionality
  • One model with multiple configurations at an exceptional price performance ratio
  • State-of-the-art algorithms for different dynamic motions of Robots, UAV, UUV, UGV, AGV, ROV, Gimbals and Antennas
  • Highly accuracy Magneto-Inductive and Fluxgate magnetometers
  • Gyro-Stabilized Slaved Magnetic Heading
  • Suitable for Primary Attitude Reference
  • Advanced Kalman Filter based sensor fusion algorithms
  • Embedded 2D and 3D magnetic calibration on hard and soft iron
  • All solid-state components (no moving parts)
  • Full temperature calibration of all sensing elements
  • Environmentally sealed (IP67) and Compact design
Dimensions 53 x 19 x 13 mm
Weight 20g
Power 5-15 VDC, 0.5W
Output Data Rate 1 – 2000 Hz
Gyro Bias In-Run Stability 2 deg/hr
Gyro ARW 0.38 deg/hr
Accel Bias In-Run Stability 0.01 mg (±8g measurement range)
Accel VRW 0.02 m/s/√hr (±8g measurement range)
Heading Accuracy 0.3 deg static
0.6 deg dynamic
Pitch & Roll Accuracy 0.05 deg static
0.08 deg dynamic
