TS-206
The TS206 is a rugged in-vehicle fanless PC with Intel 6th Gen CPU options and supporting up to 16GB of DDR3 memory. It features four PoE (Power over Ethernet) ports for the connection of mainstream IP cameras, and includes intelligent power ignition capabilities.
The versatile system features a variety of I/O and has received e-Mark automotive certification.
Specifications:
| Dimensions | 264.5 x 75.1 x 133 mm |
| Power |
12/24V 26W typical, 76W max |
| CPU | Core i7-6600U Dual Core/i5-6300U Dual Core |
| Memory | Up to 16GB DDR3 |
| Operating Temperature Range | -20 – 60°C extended |
| Expansion |
Full-size Mini PCIe w/SIM holder (PCIe, USB interface) Full-size Mini PCIe (PCIe, USB, SATA interface) 2 x Full-size Mini PCIe w/SIM holders (USB interface) 1 x removable 2.5" storage drive bay |
| I/O |
2 x Gigabit Ethernet 10/100/1000 Mbps 4 x 10/100 Mbps PoE 2 x USB 3.0 2 x USB 2.0 Optional 2-channel CANbus 6 x DI/2 x DO 2 x non-isolated RS-232/422/485 with auto flow control 2 x isolated RS-232/422/485 with auto flow control 1 x HDMI 1 x VGA |
