NuWaves Engineering Unveils 15 Watt Bidirectional Amplifiers for UAS Applications

By Mike Ball / 27 Jan 2017

NuPower 12C04A Bidirectional Amplifier
NuWaves Engineering has announced the addition of the company’s latest miniaturized bidirectional amplifier to its line of NuPower Xtender bidirectional amplifier products.

The NuPower Xtender 12C04A model (part number NW-BA-12C04A) provides 15 watts of RF power across L- & S- band frequencies of 1.0 to 2.5 GHz, ideal for extending the communication range of half-duplex transceivers with constant-envelope waveforms. Adjacent radio frequency bands, such as the popular 900 MHz Industrial, Scientific, and Medical (ISM) band are also supported at lower peak power levels. In receiver mode, the 12C04A bidirectional amplifier offers a low noise figure of 3.5 dB and a low noise amplifier that provides 13 dB of gain. The module accepts a +5 dBm input level and provides a minimum 35 dB of transmit gain, all while operating with 30% or better power efficiency.

The bidirectional amplifier features the option of manual transmit / receive (T/R) mode selection or automatic transmit sensing, coupled with an extremely fast T/R mode switch time of < 1.5 μs to support a variety of digital data links, including AeroVironment’s DDL, FreeWave Technologies’ radios, and Microhard Systems’ radios. All of this has been designed into a system with a small form factor of 6.9 in3 by utilizing state-of-the-art Gallium Nitride (GaN) power amplifier device technology. The NuPower Xtender 12C04A bidirectional amplifier module is ideal for broadband RF telemetry and communication systems that require reliability and minimal size, weight, and power consumption (SWaP).

“We are excited to offer this bidirectional amplifier module. This product is targeted at the unmanned aircraft system (UAS) market, filling the gap in the market for small bidirectional amplifiers,” said Jeff Wells, President and CEO of NuWaves Engineering. “The NuWaves team takes pride in our ability to support our clients with best-in-class RF solutions, rapidly fulfilling the ever-changing needs of the Warfighter.”
