Echoes 5000 Sub-Bottom Profiler
Echoes 5000 is an energy efficient and compact sub-bottom profiler (SBP) system allowing high resolution surveys in various operating conditions (lake, shallow & deep waters). Its design allows an easy integration with an AUV for operation down to 6 000 m. Provided with Delph Seismic acquisition software, it becomes a full-feature survey tool, easy to use, with a perfect balance between penetration and resolution.
Frequency: 2000-6000 Hz
Array: 213/291 mm (diam x H)
Weight (air/water): 11/7 kg
Set-up: Pole & Tow-Fish Mounted, AUV/ROV
Resolution: 18 cm
Mean penetration: 50 m
