Yost Labs Embedded SensorYost Labs is a leading developer of real-time inertial motion tracking solutions. Our sensor fusion technologies power low latency, high performance sensors for a wide variety of unmanned systems applications, including navigation for unmanned aerial, ground and marine vehicles, positioning and stabilization, and control.

Our 3-Space 3D inertial sensor product family offers a wide variety of communication, performance, and packaging options. Each sensor incorporates triaxial gyroscope, accelerometer, and compass sensors in conjunction with advanced processing and on-board filtering.

3-Space™ Sensor Wireless

Miniature AHRS / IMU with Wireless Communication Interface

3-Space Sensor WirelessThe 3-Space Sensor Wireless integrates a miniature Attitude and Heading Reference System (AHRS) / Inertial Measurement Unit (IMU) with a 2.4GHz DSSS wireless communication interface that delivers high performance at ranges of up to 200 feet. An integrated Lithium-Polymer battery and charge control gives a battery life of 5+ hours at full performance.

As with all our 3-Space sensors, orientation can be returned in absolute terms or relative to a designated reference orientation. The gradient descent calibration process and high update rates increase accuracy and greatly reduce and compensate for sensor error. The 3-Space Sensor system also utilizes a dynamic sensor confidence algorithm that ensures optimal accuracy and precision across a wide range of operating conditions.

Specifications:

  • Dimensions: 35mmx60mmx15mm (1.38×2.36×0.59in.)
  • Weight: 28 grams (0.98 oz)
  • Orientation range: 360º about all axes
  • Orientation accuracy: ±1º for dynamic conditions & all orientations
  • Accelerometer scale:
    • ±2g / ±4g / ±8g selectable for standard models
    • ±6g / ±12g / ±24g selectable for HH models
    • ±100g / ±200g / ±400g selectable for H3 models
  • Accelerometer resolution: 14 bit, 12 bit(HH), 12 bit(H3)
  • Gyro scale: ±250/±500/±1000/±2000 º/sec selectable
  • Gyro bias stability @ 25°C: 2.5º/hr average for all axes

More Information: 3-Space™ Sensor Wireless

3-Space™ Sensor Embedded

Ultra-Miniature Surface-Mount AHRS / IMU

3-Space Sensor EmbeddedThe 3-Space Embedded is an ultra-miniature Attitude and Heading Reference System (AHRS) / Inertial Measurement Unit (IMU) produced in a surface-mount assembly. Measuring 23mm x 23mm x 2mm and weighing only 1.3 grams, it is our smallest and lightest high-performance AHRS, making it ideal for space-constrained unmanned vehicle applications.

As with all our 3-Space sensors, the Embedded module features are accessible via a well-documented open communication protocol that allows access to all available sensor data and configuration parameters. Versatile commands allow access to raw sensor data, normalized sensor data, and filtered absolute and relative orientation outputs in multiple formats including: quaternion, Euler angles (pitch/roll/yaw), rotation matrix, axis angle, two vector (forward/up). The Embedded module also offers a range of communication interface options, including SPI, USB 2.0, and asynchronous serial.

Specifications:

  • Dimensions: 23mmx23mmx2.2mm (0.9×0.9×0.086in.)
  • Weight: 1.3 grams (0.0458 oz)
  • Power consumption: 45mA @ 5v
  • Orientation range: 360º about all axes
  • Orientation accuracy: ±1º for dynamic conditions & all orientations
  • Accelerometer scale:
    • ±2g / ±4g / ±8g selectable for standard models
    • ±6g / ±12g / ±24g selectable for HH models
    • ±100g / ±200g / ±400g selectable for H3 models
  • Accelerometer resolution: 14 bit, 12 bit(HH), 12 bit(H3)
  • Gyro scale: ±250/±500/±1000/±2000 º/sec selectable
  • Gyro bias stability @ 25°C: 2.5º/hr average for all axes

More Information: 3-Space™ Sensor Embedded

3-Space™ Sensor Watertight

Miniature AHRS / IMU Encased in Sealed Enclosure

3-Space Sensor WatertightThe 3-Space Watertight is a miniature high-precision Attitude and Heading Reference System (AHRS) / Inertial Measurement Unit (IMU) encased in an end-use-ready IP67 sealed enclosure. The IP67 rated connector provides power as well as communications via USB 2.0 and RS232 connections.

Specifications:

  • Dimensions: 35mmx67.6mmx20mm (1.38×2.66×0.79 in.)
  • Weight: 21 grams (0.74 oz)
  • Orientation range: 360º about all axes
  • Orientation accuracy: ±1º for dynamic conditions & all orientations
  • Accelerometer scale:
    • ±2g / ±4g / ±8g selectable for standard models
    • ±6g / ±12g / ±24g selectable for HH models
    • ±100g / ±200g / ±400g selectable for H3 models
  • Accelerometer resolution: 14 bit, 12 bit(HH), 12 bit(H3)
  • Gyro scale: ±250/±500/±1000/±2000 º/sec selectable
  • Gyro bias stability @ 25°C: 2.5º/hr average for all axes

More Information: 3-Space™ Sensor Watertight

3-Space™ Sensor Bluetooth

Miniature AHRS / IMU with Bluetooth Communications Interface

3-Space Sensor BluetoothThe 3-Space Bluetooth integrates a miniature Attitude and Heading Reference System (AHRS) / Inertial Measurement Unit (IMU) with a 2.4GHz Bluetooth v2.0+EDR Class 1 communications interface and a rechargeable lithium-polymer battery with charge control.

The Bluetooth wireless interface allows for high-performance communication at ranges of up to 300 feet.  A USB 2.0 interface is also included that provides both power and communications.

Specifications:

  • Dimensions: 35mmx60mmx15mm (1.38×2.36×0.59in.)
  • Weight: 28 grams (0.98 oz)
  • Orientation range: 360º about all axes
  • Orientation accuracy: ±1º for dynamic conditions & all orientations
  • Accelerometer scale:
    • ±2g / ±4g / ±8g selectable for standard models
    • ±6g / ±12g / ±24g selectable for HH models
    • ±100g / ±200g / ±400g selectable for H3 models
  • Accelerometer resolution: 14 bit, 12 bit(HH), 12 bit(H3)
  • Gyro scale: ±250/±500/±1000/±2000 º/sec selectable
  • Gyro bias stability @ 25°C: 2.5º/hr average for all axes

More Information: 3-Space™ Sensor Bluetooth
